• PolyPhaser DGXZ+15DMDF-A Hybrid +15VDC Pass RF Lightning

PolyPhaser DGXZ+15DMDF-A Hybrid +15VDC Pass RF Lightning Protector, 800MHz - 2.5GHz, DIN-Male to DIN-Female

Brand PolyPhaser
Part Number DGXZ+15DMDF-A

Quick look

Product Types: Lightning Arrestors
$201.99
Pricing may be subject to tariffs.

1-888-WINNCOM / sales@winncom.com

Get your business the equipment it needs with LEAF.

GX Series


The GX Series of RF DC pass surge arrestors are engineered for RF coaxial applications where DC current is needed on the coaxial line. The GX Series can be used on GPS and other active antenna systems that operate in the range from DC to 2700 MHz.


FEATURES


* Frequency ranges from DC to 2.7 GHz


* Patented hybrid surge protection


* Repeatable RF performance after surge


* Flexible bulkhead and bracket mounting options


* Weatherproof when installed


* 7/16? DIN, N-Type and TNC


STANDARDS


* Weatherproof: IEC 60529 IP 67


* Bellcore TA-NWT-000487


* Procedure 4.11, Wind Driven (120 MPH)


* CE and RoHS


PATENTED LIGHTNING ARRESTOR TECHNOLOGY


protection technology. This hybrid circuit integrates the quick response of a silicon avalanche suppression diode (SASD) with the surge handling capabilities of a MOV and gas tube. The GX technology has been field tested for more than a decade and has been used in critical RF networks world-wide.


Data Sheet

Product Types Lightning Arrestors
