• PolyPhaser Bulkhead Coaxial RF Surge Protector

PolyPhaser Bulkhead Coaxial RF Surge Protector, DC - 6GHz, 90W, 60V Max, 20kA, Gas Discharge Tube, N-Female

Brand PolyPhaser
Part Number GT-NFF-AL

Quick look

Product Types: Lightning Arrestors
$69.99
Pricing may be subject to tariffs.

1-888-WINNCOM / sales@winncom.com

Get your business the equipment it needs with LEAF.

Gas tube lightning protection with excellent VSWR and superior RF performance characteristics for equipment operating between dc and 7 GHz with up to 90 W RF power configured with N female connectors - bidirectional.


Features


- Aluminum Construction


- Weather Proof When Installed


Specifications for PolyPhaser GT-NFF-AL


Mount Type - Bulkhead Mount


Standards - CE Compliant, RoHS Compliant


Line Voltage - 50 Vdc Max


Frequency Range - dc to 7.0 GHz


Protected Side Connector - N Female


Surge Side Connector - N Female


Turn On Voltage - 150 Vdc (spark over)


VSWR - dc TO 3.0GHz @ =1.1dB TO 1 dc TO 4.0Ghz @ =1.2bB TO 1 dc TO 7.0Ghz @ =1.4 TO 1


Insertion Loss - dc TO 4.0Ghz @ =0.1dB dc TO 7.0GHz @ =0.25dB


RF Power - 90W/CW @ 30MHz, 9W/CW @ 3GHz


Data Sheet

Product Types Lightning Arrestors
