4 Port Midspan, Very High Power 1.8A per port, Gigabit Passive PoE Injector, 4 Pair output, 20V to 60V operation

TP-MS4G-VHP - 4 port PoE Gigabit Midspan UniVolt Injector

The TP-MS4G-VHP mid span PoE power sources are used for supplying PoE and data to multiple devices from a central location such as an operations room or equipment cabinet. The PoE devices feature a separate data-in port coupled with a data out/PoE port. The PoE function is considered 4 Pair Passive PoE which is sometimes referred to as ``High PoE''. The units support Gigabit Ethernet and are backward compatible to 10/100MB.

The Midspan features Universal Voltage (UniVolt[tm]) PoE outputs where the PoE voltage equals the input voltage. All ports will have the same PoE voltage.

PoE DC Voltage (20V-60V) is supplied on pins 1,2 (V-), 3,6 (V+) and 4,5 (V+) and 7,8 (V-). The unit can accept + or - voltage on input however the design is a non-isolated design. Maximum power output per port is 1.8A. The individual outputs are overcurrent, over/under voltage and short circuit protected.

The midspan is DIN Rail mountable with the included DIN Rail brackets.

Features

* Very High Power, Gigabit 4 Port Midspan PoE Injector

* Up to 1.8A per Individual Port

* Universal PoE Voltage 20VDC to 60VDC.

* Powers Passive PoE Devices using 4 pair power

* DIN Rail Mountable - Includes DIN Rail adapters
