LM-Series SM OSP MicroCore Fiber Optic Cable with 96 Fibers, Single Mode (OS1), 24 Tubes with 4 Fibers (2 Fillers), Micro-Duct,

LM-Series OSP MicroCore® Cable

AFL OSP MicroCore® cable series (LM-Series) is designed for outside plant installation in microduct conduit systems. The foundation of the design is the multi-fiber-set, gel-filled buffer tube construction. The kink-resistant buffer tube contains multiple 12-fiber sets of color-coded fibers. Each set within the buffer tube is grouped using dual color-coded binder threads. The dry-blocked core is made up of SZ-stranded buffer tubes around a central strength member. The low-friction, high-strength overall jacketing system protects the cable-core while providing an optimized cable package supporting high-speed, long-distance jetting performance. The unique, high-fiber density geometry yields a cable construction that can accommodate up to 432 fibers and can be blown into microducts ranging in inside diameters from 10 mm to 16 mm.

Features

* 12 up to 432 250 ìm fibers

* Low-friction outer jacket designed for air-blown installations

* Robust, kink-resistant buffer tubes reduce time and handling issues associated with enclosure buildouts

* 300lb installation tensile load rating

* OD compatible with 10 mm to 16 mm inside diameter microducts

Applications

* Long-haul, middle-mile and metro-loop

* Campus inter-building backbone distribution

* Low-cost fiber upgrade migration strategies
