Cable 3/8" Low Loss 400-type SOI

MIG-400 Low Loss Coaxial Cable, Solid BCCA Conductor for the Wireless Industry

Our MIG-400 Coaxial Cable is commonly used for short Antenna Feeder Runs, Drop-in replacement for RG-8 and any application requiring an easily routed low-loss RF cable. The MIG-400 Coax Cable has a denser jacket and thicker conductor then RG11, so it can transfer data at double the speed. We supply only high-performance coaxial cable for data networking and radio applications. MIG-400-Series cable offers equivalent or better characteristics and performance than other existing industry cables. We supply dual shield cable to maximize signal retention for even sharper, clearer digital pictures. Our MIG-400 series low loss coaxial cable is designed for low loss general purpose applications with a flexible outer insulation for a superior bend radius.

Applications

Coaxial Cable is used to transmit radiofrequency energy. The advantage of coaxial is that the electromagnetic field carrying the signal occurs only in the space between the inner and outer conductors. With that said, it allows the cable to be installed next to metal objects without power loss. Coaxial Cable also provides protection of the signal from external electromagnetic interference. Coaxial Cables connects radio transmitters and receivers to their antennas, computer network (Internet) connections, digital audio (S/PDIF), and distributing cable television signals. The cable is used for antenna coaxial cable applications.

Product Quality

Our high-quality MIG-400 Low Loss RF Cable consists of a 2.74mm solid Bare Copper (BC) inner conductor. It is wrapped in a dielectric polyethylene insulation. Our Coax Cable comes with 90% Tinned Copper (TC) braid shielding and Bonded AL Foil. The cable is covered with a flame-rated PVC jacket (CM) for outdoor use.
