FAL 124 2365, MINI-LINK 6352 (ML6352) TX HP License, Enables High output power (last 4 dB) for transmission on the radio

MINI-LINK 6352

Building an efficient microwave backhaul network with end-to-end performance in mind; requires high node capacity, compact and modular building practice and advanced packet functionality. The microwave nodes also need to be capable of handling single hops as well as advanced hub sites for larger networks. By combining MINI-LINK outdoor units and indoor units, all network scenarios are supported with superior performance and lowest possible cost of ownership.

Very High Capacity Microwave

MINI-LINK 6352 is an all outdoor microwave node, and part of the successful MINI-LINK portfolio.

MINI-LINK 6352 provides up to 10 Gbps capacity over a 2000 MHz channel in the E-band (70/80GHz). MINI-LINK 6352 also supports 2+0 Radio Link Bonding with XPIC and 1+1/2+0 Equipment Protection (EQP) as well as Multi-Band Booster configurations together with MINI-LINK 6600/TN. For maximum connectivity, MINI-LINK 6352 is equipped with multiple 10 GE interfaces.

Network scenarios

MINI-LINK 6352 has an embedded L2 switch, enabling aggregation and switching between all traffic ports, that makes it ideal for multiple combinations of mobile backhaul solutions. Use it as an all outdoor solution, aggregating multiple south-bound directions to one high capacity northbound direction. MINI-LINK 6352 is also suitable for cascading or as a repeater solution. It can also be connected to any other MINI-LINK indoor unit using available Ethernet ports.

MINI-LINK 6352 is also suitable in applications such as Fixed Broadband, Fiber extension, and Enterprise connectivity.

Multi-band Booster

Multi-band booster enables E-band to be used over longer distances and much wider areas outside dense urban areas. By bonding MINI-LINK 6352 with MINI-LINK 6600 or TN (6-42 GHz), the hop-length can be extended up to three times with high performance.

Network Synchronization

MINI-LINK 6352 supports transport of synchronization signal across the hop. The synchronization signal is carried over the radio hop without occupying any bandwidth allocated for payload traffic. MINI-LINK 6352 also supports PTP synchronization according to IEEE 1588v2.

Low Delay

The delay performance is typically as low as 30 up to 90 ìs, depending on channel bandwidth, enabling best possible end user experience.

Adaptive Coding, Modulation and Bandwidth (ACMB)

The radio link supports hitless adaptive modulation, adaptive coding and adaptive bandwidth, for BPSK-512 QAM which provides an error free transmission and constant delay variation securing sync performance.

Header Compression

MINI-LINK 6352 supports multi-layer header compression as well as payload compression enabling typically 20% extra capacity.

Line-of-Sight (LOS) and Non-Line-of-Sight (NLOS)

MINI-LINK 6352 supports both LOS and NLOS configurations. This will give operators greater flexibility to deploy outdoor small cells, enabling high network performance.
