PTP550E 4.9-6.2GHz Integrated 23 dBi Antenna End with AC Power Supply, Mounting Bracket and No Line Cord, RoW version

PTP 550E - 1.4 Gbit CAPACITY

Cambium Network is excited to introduce our latest Point to Point Gigabit throughput solution based on 802.11 ac Wave 2 operating in 5 GHz wireless space, addressing the gigabit capacity needs for high speed backhaul solutions in mid-range and long-range applications. The PTP 550E solution draws its attributes from Cambium Networks' Point to Point products such as PTP 650/670 and PTP 450i.

METAL HOUSING

Each PTP 550 comes with IP66/67 Metal enclosure, which protects the radio from extreme condition and solar radiation.

ANTENNA ALIGNMENT

The ``e-alignment'' GUI provides the installer with an accurate and reliable way of installing PTP 550E.

CHANNEL BONDING

Each channel can have independent channel bandwidth that provides for flexibility in channel selection, band selection and address throughput requirements. Using two 80 MHz channel the PTP 550E achieves 1.4 Gbps.

Dynamic Channel Selection (DCS)

With Dynamic Channel Selection, PTP 550E systems constantly optimize the channel of operation to maximize link reliability and performance. Responding to the radio interference environment, PTP 550E will search for the clearest spectrum and move to it seamlessly. The customer benefits from best available throughput with limited spectrum in the most challenging environments.

OTHER KEY FEATURES

* 4.9 to 6.2 GHz

* Up to 1.4 Gbps

* Built in Live Spectrum analyzer

* IPv6/IPv4 dual-stack management support

* AES 128 Encryption

* LINKPlanner Support

* cnMaestro Support
