NXW Liquid-cooled Stainless Steel Housing w/ ONXAB (Requires ONXWTG or ONXWVG)

Brand Videotec
Part Number NXW0K1000

Quick look

Product Types: Environmental Enclosures
Product Features: Outdoor

1-888-WINNCOM / sales@winncom.com

Get your business the equipment it needs with LEAF.

NXW - Stainless Steel Liquid-cooled housing


- Designed to operate in high temperature environments


- AISI 316 stainless steel double chamber


- Weatherproof standard IP66/IP67


The solid construction of this housing makes it suitable for heavy duty applications, such as the surveillance of ovens, foundries and other high temperature environments.


The NXW housing is entirely constructed from electropolished stainless steel and consists of a body with a double chamber for the circulation of a cooling liquid or air. The N XW is enclosed by two thick flanges at either end and allows cables to pass through by means of two PG13.5 cable glands on the back flange. The front flange can be equipped with tempered glass, I R glass or Vicor glass for higher temperature.


A special version is available with IR-proof glass.


Two 1/2'' GAS connectors allow for the cooling liquid inflow/outflow.


The N XW is equipped with a flange designed to create an air barrier in front of the glass. This prevents the formation of dust deposits and attenuates the heat of the glass itself. With the supplied air barrier, the NXFIGRU filter group is recommended, to purify the air drawn from a compressor.


Data Sheet

Product Types Environmental Enclosures
Product Features Outdoor
